Specification | |
Items | Standard |
Rating | 1A 30V DC |
Insulation resistance | 100 MΩ min. 100V DC |
Dielectric strength | 250V AC for 1 min |
Contact resistance | 150MΩ max. |
Operating temperature range | ‘-5°c to +35℃ |
Lifetime | 10,000 Cycles min. |
Operating force | 400-1000gf |
Travel | 2.0 ± 0.1mm |
Compressive strength | AC 500V 50Hz/1 min |
